Kenmore Thermostat/heating element installation
Asked Jun 16, 2008, 09:50 AM
I have a Kenmore 70 series dryer (model #110.96576200) and have a bit of a problem. I removed a faulty heating element, threw it away without thinking of removing the thermostat. Now I've got a new heating element and a replacement thermostat and I can't figure out how it fits into the element? I've got 2 main pieces, the actual thermostat, and another "plug plate". Also have a jumper cable w/ screws. Is there a diagram out there that can show me how this all fits together? I've been to ManageMyHome and SearsPartDirect, can't seem to find the answer I'm looking for. Can anyone help please?
